RICON 13 x 70 EA Stainless Steel Beam Hanger

The RICON 13 x 70 EA Stainless Steel Beam Hanger is a compact concealed single connection system designed for precise and durable joints in small-scale timber assemblies. Made from A2 stainless steel, it provides excellent corrosion resistance for both indoor and outdoor applications, making it ideal for exposed structures in Service Class 3 environments.

Each connector consists of two identical stainless steel plates that interlock in a dovetail-like configuration. Despite its small size, the system delivers reliable load transfer and long-term performance. Installation is fast and repeatable using the included A2 stainless steel screws, and the connection can be fully concealed or visible as needed.

Key Features

• Concealed single connection for small timber joints

• Compact 70 mm stainless steel plates with 13 mm profile width

• Load capacity up to 4.8 kN (insertion direction, per ETA 10/0189 with KNAPP A2 screws)

• Made from AISI 304 (A2) stainless steel for outdoor and humid environments

• Ideal for small timber members and fine architectural joinery

• Self-tightening dovetail engagement ensures precise fit and stability

• Adjustable to correct minor installation tolerances

• Reusable and demountable for prefabricated or modular use

• Optional A4 stainless steel version available for marine or highly corrosive conditions

• Outdoor and indoor furniture assembly

• Pergolas, canopies, and compact timber structures

• Balcony and decking components

• Playground and sports structures

• Decorative and architectural timber joinery

• Hybrid wood-to-steel or wood-to-concrete applications

• Type: RICON 13 × 70 EA Stainless Steel Single Connection

• Load Capacity (F₂,Rk): 4.8 kN (per ETA 10/0189 with KNAPP stainless steel CS-screws)

• Material: AISI 304 (A2) stainless steel (optional A4 available)

• Kit Includes:

  • 2 × RICON 13 × 70 stainless steel plates

  • 3 × self-tapping stainless steel screws A2 5×50 mm

  • 3 × self-tapping stainless steel screws A2 5×80 mm

  • 1 × stainless steel locking bracket (13 mm)

• Fire Resistance: R30 ≥ 20 mm, R60 ≥ 40 mm (four-sided concealed installation)

• ETA Extension: Approved for hardwoods and impregnated timbers (oak, larch, Accoya)

• Mill a recess into the timber component according to the routing template.

• Mount one stainless steel plate using A2 self-tapping screws (5×50 mm and 5×80 mm).

• Attach the opposite plate to the mating surface (beam, post, or wall).

• Align and slide the plates together until fully interlocked.

• Secure with the included stainless steel locking bracket if required.

• Verify alignment and tighten all fasteners to specification.
