TUCK Compression Dowel – Sample Pack

The TUCK Sample Pack includes 25 compression dowels designed for fast, glue-free assembly of furniture and case goods. Each TUCK dowel is made from spring steel, providing immediate holding power and long-term tension without the need for clamps.

Included in the pack:

• 5 × TUCK 6×25 mm

• 5 × TUCK 8×35 mm

• 5 × TUCK 10×32 mm

• 5 × TUCK 10×28 mm

• 5 × TUCK 10×16 mm

The TUCK dowel acts as a self-tightening connector, creating an instant, load-bearing joint. Its spring steel body exerts consistent pressure on the borehole walls, ensuring a snug fit over time. Available in multiple diameters and lengths, the TUCK can be inserted manually or with dowel-boring or CNC equipment for both small shops and industrial manufacturing.

Features and Benefits

• Instant, load-bearing connection with no glue or clamps required

• Reduces assembly time and eliminates curing delays

• Self-tightening spring steel maintains tension over time

• Concealed connector for clean design and finished appearance

• Ideal as a clamping aid or stand-alone fastener

• Compatible with both solid wood and composite materials

• Case goods and cabinetry

• Furniture and millwork

• Stair construction and interior joinery

• Architectural and shopfitting applications

• Moldings, trim, and gluing aids

• Quantity included: 25 dowels

• Material: Spring steel (black finish)

• Coating: None

• Connector type: Self-tightening compression dowel

• Mounting: Insert directly into pre-drilled boreholes; no adhesive or clamps required

• Advantages: Concealed, self-tightening, immediately load-bearing connector

• Suitable materials: All wood and board materials (solid and composite)

• Recommended tools: Doweling jig, cordless drill, CNC dowel inserter

• What is included: 25 TUCK compression dowels in assorted sizes

Steps

1. Pre-drill boreholes based on dowel size:

   • Ø 6 mm × 25 mm → drill depth 25 mm

   • Ø 8 mm × 35 mm → drill depth 35 mm

   • Ø 10 mm × 32 mm → drill depth 32 mm

   • Ø 10 mm × 28 mm → drill depth 28 mm

   • Ø 10 mm × 16 mm → drill depth 16 mm

2. Insert the TUCK dowel into one workpiece (surface application recommended).

3. Align and attach the mating workpiece using a rubber mallet.

4. Optional: Apply a small amount of KNAPP Adhesive PU+ to the edges before assembly for additional bond strength.

Tips

• Strike the parts together using light, even blows rather than forcing from above on a hard surface.

• For large or heavy assemblies, temporary clamping may assist alignment but can be removed immediately after joining.

• The TUCK dowel’s spring steel design eliminates the need for curing time, allowing components to be used or handled right after assembly.

• For glued joints, it is not necessary to wait for full adhesive hardening.
