Zipbolt UT Drawbolt – 6 x 100 mm

The 10.900 Zipbolt UT Drawbolt is a compact, high-performance connector engineered for fast and reliable assembly of worktops, countertops, and panels. With a slim 12.5 mm (1/2 in) profile and durable all-metal housing, it delivers strong, secure joints while fitting seamlessly into tight spaces.

Ideal for both professional installers and DIY applications, the 10.900 simplifies the joining process with precision gear-drive technology that ensures consistent tightening every time.

Key Features

• Compact 12.5 mm profile with robust all-metal construction

• Fast and efficient joining for countertops and panels

• Quick tightening using a 4 mm hex bit

• Concealed design for a clean, professional finish

• Reliable performance for professional and residential use

• Kitchen and bathroom countertops

• Furniture and cabinet assembly

• Commercial and residential joinery

• Interior and exterior fit-outs

• Panel, frame, and fixture connections

• Dimensions: 100 × 20 mm

• Material: All-metal diecast housing

• Finish: Zinc-plated for corrosion resistance

• Connector type: Gear-driven drawbolt connector

• Drive type: 4 mm hex bit

• Advantages: Compact design, fast assembly, and long-lasting hold

• Recommended accessories:

  • Routing Template 40.200 for precise recess cutting

  • Standard 4 mm hex bit

Steps

1. Use the 40.200 Routing Template (sold separately) to create the proper recess slot.

2. Position the 10.900 Zipbolt UT Drawbolt within the routed pocket.

3. Engage the gear mechanism using a 4 mm hex bit until the connection is secure.

4. Confirm the joint is fully aligned and seated flush.

Tips

• Avoid using an impact driver to preserve the gear system.

• Ideal for use with CNC or manual routing setups.

• Works well in compact applications where space is limited.

• Delivers a strong and clean joint without visible hardware.
